380V Ultrapure Water Equipment , Two Stage 50T/H Purification Filter Carbon Steel RO Water Treatment Plant

Basic Information
Place of Origin: Guangzhou, China
Brand Name: Kaiyuan
Certification: ISO9001, CE, SGS
Model Number: KYRO-50TPH
Minimum Order Quantity: >= 1sets
Price: negotiation
Packaging Details: export standard wooden case(plywood), no need to fumigate, suitable for shipping.
Delivery Time: 7-12working days (depand on raw materials stocking)
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: >300sets/month
Detail Information
RO Membrane: USA DOW Production Capacity: 50T/H
Recovery Rate: More Than 75% Electrical Power: 220V 380V OR OTHER
Tank Material: Carbon Steel Usages: Purification Process
High Pressure Pump: CNP Nanfang Desalination Rate: >=97%
High Light:

pure and clear water filter system

,

ultrapure water equipment


Product Description

Ultrapure Water System Two Stage 50T/H Purification Filter Carbon Steel RO Water Treatment Plant



Reverse Osmosis water purification machine can be used in circuit,electron,optics,chemical,petroleum,surface treatment and other industries with pure water. Raw water can be from lake, ground water, sea water,etc.The water after treatment can be used for medical and pharmaceutical ,drinking pure water.



Design basis and treated water standard

Raw water : Raw water quality analysis report( Better provide this to manufacture)

Raw water: Underground water

Produced water's application: Manufacture agrochemical

The capacity of produced water : 250L/H - 50000L/H

System Configuration : Pre-treatment + One/Two Stage RO Water Purification System +Post Treatment

Designed Recovery : 75%

Rejection rate : ≥ 97%

Operation time up to 20hours per day

Installation condition:Interior systems installation;Temperature:5-39℃

Voltage : 220V / 380V, single phase / 3 phase, 50Hz / 60Hz

Effluent standards: Feed water conductivity ≤500μs/cm, water conductivity ≤10μs/cm (desalting rate is 96-98%).



Raw water source:Bore whole, river, well, mountain spring, lake, etc
Raw water pump/multi pump:Nanfang, Grundfos
Filter media:Quartz sand filter, active carbon filter, security filter( PP filter)
RO Membrane:Filmtec Dow,Hydranautics




Working process



1. Booster pump-- provide the pressure to quartz sand filter/active carbon filter.
2. Quartz Sand filter-- get rid of turbidity, suspended matter, organic matter, colloid, ect.
3. Active Carbon filter--Remove the color, free chloride, organic matter, harmful matter, ect.
4. Softener--exchange "ions" of calcium and magnesium with the most common and easiest method.
5. Security filter--prevent large particles, bacteria, viruses into RO membrane, accuracy is 5um
6. High pressure pump-- Provide the high pressure to RO membrane ro
7.RO system-- main part of the plant. The RO membrane's desalting rate can reach 99%, removing over 99% ions.

.

380V Ultrapure Water Equipment , Two Stage 50T/H Purification Filter Carbon Steel RO Water Treatment Plant 0

Main Features

1. Automatic backwash and manual backwash
2. Automatic switch on when low water level, and switch off when high water level
3. This system occupy little space, easy to operate, wide application range.
4. Reverse osmosis desalting rate ≥99%, machine desalting rate ≥97%. 98% of organic matters, colloids and bacteria can be removed.
5. Finished water under good electric conductivity, one stage≤10μs/cm, two stage around 2-3μs/cm, EDI ≤0.5μs/cm

Application

1.Textile, chemical industry, process water / chemical recycled water, chemical products manufacturing purification and preparation of water ;

2.Food and beverage industrial water, purified drinking water, beverages, beer, liquor, health care products such as water purification and preparation of water;

3.Seawater, brackish water desalination islands, ships, offshore drilling platforms, brackish water areas

4.Larger community, real estate property, schools, factories, hospitals, and the restaurants, hotels, beauty salons, canteens and other various types of enterprises and institutions.

5.Integrated circuits, silicon wafers, display tubes and other electronic components of electronic industrial water rinse water

6.Can be used for filling water bottled water, mineral water and other preparation work



380V Ultrapure Water Equipment , Two Stage 50T/H Purification Filter Carbon Steel RO Water Treatment Plant 1


Photo Show


380V Ultrapure Water Equipment , Two Stage 50T/H Purification Filter Carbon Steel RO Water Treatment Plant 2

380V Ultrapure Water Equipment , Two Stage 50T/H Purification Filter Carbon Steel RO Water Treatment Plant 3



Install in Saudi Arabia

380V Ultrapure Water Equipment , Two Stage 50T/H Purification Filter Carbon Steel RO Water Treatment Plant 4

Welcome to visit our factory
