|Place of Origin:||Guangzhou, China|
|Certification:||ISO9001, CE, SGS|
|Minimum Order Quantity:||negotiation|
|Packaging Details:||export standard wooden case(plywood), no need to fumigate, suitable for shipping.|
|Delivery Time:||15-30working days(depand on raw materials stocking)|
|Payment Terms:||L/C, D/A, D/P, T/T, Western Union, MoneyGram|
|Name:||Industrial RO System 8000L/H Water Treatment Plant||Pretreatment:||Quartz Sand/ Activated Carbon/ Security PP Filter|
|Application:||Drinking Water Treatment||RO Membrane:||LCLE-4040、BW30-400|
|Electrical Power:||110V/220V/380V||Production Capacity:||8000L/H|
|Tank Material:||FRP/ Stainless Steel/ Carbon Steel||Control Valve:||Automatic|
|Pipe Fitting:||SUS304/ U-PVC||Pump:||CNP|
|Activated Carbon:||25KG/bag||Optional:||PLC Touch Screen/ Regulating Wheels/ Two-stage RO System|
8TPH RO Water Treatment System,
50Hz RO Water Treatment System
8000L/H Stainless Steel ro water filter Water Treatment Plant For Drinking /Beverage
INFRMATION OF THE MACHINE
|Voltage||380V/3ph/50Hz (customize available)|
|Desalination rate||> 97%|
|Material||FRP, Stainless Steel , U-PVC|
|Configurations||CNP pump&USA DOW membrane|
|Certification||CE & ISO & SGS|
The basic working principle of reverse osmosis
1. Using a special high-pressure water pump, the raw water is added to a pressure of 6-20 kg, so that the raw water permeates through the reverse osmosis membrane with a pore diameter of only 0.0001 μm under the action of pressure.
2, Chemical ions and bacteria, fungi, virions can not pass, with the discharge of wastewater, only allow water molecules and solvents less than 0.0001 microns to pass.
3. The security filter is equipped with a filter element with a filter aperture of 5μm. These filters filter out any particles larger than 5μm.
4. The more common type of permeable membrane is a polyamide membrane, and the membrane type is a wound composite membrane. The membrane has a salt removal rate of 99.5%.
5, Because the RO membrane is susceptible to the pH value, residual chlorine and water temperature in the water, the RO membrane has strict requirements on the water quality before the operation:
PH value: 3~10
Residual chlorine value: <0.1mg/L
SDI15 value: <5.0
Water temperature: <45 °C
|1. System can produce water continuously, PLC program controlled, Simple in installation and operation|
|2. RO system be chosen the import USA DOW membrane|
|3. Tank level control, automatic stop when the raw water tank without water or pure water tank is full|
|4. RO system flushes RO membranes when it starts to work so that membrane fouling is reduced.|
|5. Nanfang(CNP) high pressure pumps or Denmark Grundfos high pressure pumps are adopted.|
|6. Product water quality is continuously monitored by conductivity meter.|
1. High operation automation degree.
1) Automatic stopping in case of sufficient water under low pressure
a) Protection of hydraulic fluctuation resistance
b) Timed flushing of front filtering materials by automatic controller
c) Automatic flushing of reverse osmosis film by IC microcomputer controller
d) Automatic monitoring of water quality
2. Small landing area, low energy consumption, free of pollution, simple process, high water quality and easy operation and maintenance
3. High removing rate, above 97% for dissolved salts, above 98% for organic substances, and above98% for colloids, bacteria and heat sources etc.
Process: raw water tank + raw water pump + quartz sand filter + activated carbon filter + water softener/chemical dosing system(optional) + security filter + high pressure pump + ro system + pure water tank + UV sterilizer(ozone generator) + precision filter + water supply point
¶ Optimal Configuration, computer-aided design, efficient power with low consumption.
¶ High efficiency filter, multi-grade stainless steel high pressure centrifugal pump, the world-renowned brands such as membrane components are standard equipment, excellent performance, can operate continuously for long time.
¶ Stable water quality: Advanced water testing control and excellent maintenance program to ensure water quality long-term stability.
¶ Highly intelligent ,especially for large and medium projects.
¶ Applies to a wide range of raw water temperature: the brackish water desalination unit has its own patent design techniques to be at 5 °C-39 °C in the temperature range of full load, the water temperature decreases will not affect output water capacity to ensure that customers are able to get rating produced water capacity.
¶ Modularized design, easy installation.
REVERSE OSMOSIS SYSTEMS IN GENERAL :
Reverse osmosis systems, with the most general definition, is removal process of the anion and cation ions by an advanced filtration method which the highest technologies are used as a water treatment system. Water is forced to pass from semi-permeable membranes by applying high pressure. Water cross flows from the surface to the center of the membrane. During this transition, organic and inorganic substances, heavy metals, projects veins, bacteria etc. in the structure of the water retains by the membrane and discharges from the concentrate line. 95% to 99% Purified water can be collected to a tank through permate line. System autoflush before the production starts in order to clean the surface of the membrane.
In this type of systems, for longer and effective use of membranes, pre-filtration and dosing systems must be done correctly.
This water treatment system uses mechanical filters, activated carbon filter as a pre-class treatment, the effective removal of suspended solids in raw water, sediment particles , organic colloids, organic matter, odor, chlorine and other impurities, with pre-programmed as a reverse osmosis desalination plant to remove the raw water. Most of the dissolved salts, bacteria, hot stream and so on, to ensure finished water quality standards.
Thank you so much for your value time.Any questions please click "contact now" send us inquiry !We will reply you within 24 hours. Tel/whatsapp/wechat: +86-13660858152
Guidelines for getting a proper quotation
Tell us the raw water/source of water
Provide water analysis report
Required production capacity( 500 liters per hour, 1000liters per hour…)
What's the pure water used for( drinking, bottle water or industrial use…)
