0.75T/H RO Water Treatment System , Automatic Reverse Osmosis Water System For Home

Basic Information

Place of Origin:	Guangzhou, China
Brand Name:	Kaiyuan
Certification:	ISO9001, CE, SGS
Model Number:	KYRO-750LPH

Minimum Order Quantity:	>= 1sets
Price:	negotiation
Packaging Details:	export standard wooden case(plywood), no need to fumigate, suitable for shipping.
Delivery Time:	1-7working days(depand on raw materials stocking)
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	>300sets/month

Get Best Price Contact Now

Detail Information

RO Membrane:	USA DOW	Production Capacity:	750liters Per Hour
Recovery Rate:	50%-75%	Electrical Power:	220/380V 50/60Hz
Tank Material:	FRP/ Stainless Steel/ Carbon Steel	Control Valve:	Automatic/ Manual
Pipe Fitting:	SUS304/ U-PVC	Warranty:	1 Year
Size:	15506201670MM	Weight:	200KG
Feed Water TDS:	<2000mg/L	Desalination Rate:	>=97%
High Light:	reverse osmosis water filter system , domestic water purification system

Product Description

750LPH RO Water Purification System for Drinking with DOW Membrane

1. Product Description

Kaiyuan Water Treatment System

Raw water Tank(Equipped by user) → Raw water pump → Quartz Sand filter → Activated Carbon filter → Water softener (optional) → Security (Cartridge) filter → High Pressure Pump→ RO system → Pure water tank(Equipped by user)

RO water purification system is to produce high quality drinking water for drinking or beverage factory etc.

1. Raw water pump-- provide the pressure to sand/carbon filter

2. Sand filter-- get rid of turbidity, suspended matter, organic matter, colloid and so on

3. Carbon filter--Remove the color, free chloride, organic matter, harmful matter and so on

4.Softener ---Hard water is softened by removing the calcium magnesium it contains.

5. Micron filter--prevent any deposition of large Particles, some bacteria, and viruses into the RO membrane, The accuracy is 5um, for holding back any large particulates such as large iron, dust, suspended matter, impurity.

6. High pressure pump-- Provide the high pressure to RO membrane, at least 2.0 MPA

7. RO system --RO system is the heart part of pure water plant. The RO systems are capable of removing over 99% of ions, bacteria, particles and 98% of organics and silica, 85 % of B. simply operation and life span.

2.Product Details

Kaiyuan Water Treatment System

kyro-750lph RO Water Purification System

1. Capacity: 750L/H EDI

2. Rated power: 2.5KW/H

3. Voltage: 110V - 415V, 50Hz / 60Hz, single phase / 3phase

4. Desalting rate:>=97%

5. Water recovery rate: 50-75%

6. Rack Size: 1870*630*1850mm

3. Features

Kaiyuan Water Treatment System

◊ This system occupy little space, easy to operate, wide application field.

◊ High operation automation degree. It is unattended.

◊ Imported parts account for over 90%.

◊ Reverse osmosis desalting rate ≥99%, machine desalting rate ≥97%. 98% of organic matters, colloids and bacteria can be removed.

◊ Automatic flushing of reverse osmosis film by IC microcomputer controller. Online display of raw water and pure water electric conductivity.

◊ Finished water under good electric conductivity, one stage≤10μs/cm, two stage around 2-3μs/cm, EDI ≤0.5μs/cm (base on raw water ≤300μs/cm).

4. Advantages

Kaiyuan Water Treatment System

1. Running stable high desalination and recovery rate;

2. Easy to operate and small maintenance workload;

3. Compact structure and saves installation place;

4. Highly efficient and low energy consumption ;

5. No secondary pollution and low operation cost.

5. Assembles

Kaiyuan Water Treatment System

What and when consumables should be placed?

No.	Consumables	Life Span
1	Quartz Sand	3 years
2	Activated Carbon	3 years
3	Water Softening Resin	1 year
4	PP Filter	3~6 months
5	RO Membrane	24~36 months
6	UV Lamp	1 year

Notice, all the consumable replace period will be depend on the feed water quality.

The better water quality, the longer replace time^^

6. Application

Kaiyuan Water Treatment System

0.75T/H RO Water Treatment System , Automatic Reverse Osmosis Water System For Home 0

7. Photo Show

Kaiyuan Water Treatment System

0.75T/H RO Water Treatment System , Automatic Reverse Osmosis Water System For Home 1

0.75T/H RO Water Treatment System , Automatic Reverse Osmosis Water System For Home 2

Warmly Welcome to Visit Us^^
