|Place of Origin:||Guangzhou, China|
|Certification:||ISO9001, CE, SGS|
|Minimum Order Quantity:||>= 1sets|
|Packaging Details:||export standard wooden case(plywood), no need to fumigate, suitable for shipping.|
|Delivery Time:||1-7working days(depand on raw materials stocking)|
|Payment Terms:||L/C, D/A, D/P, T/T, Western Union, MoneyGram|
|RO Membrane:||USA DOW||Production Capacity:||2000liters Per Hour|
|Recovery Rate:||50% - 75%||Electrical Power:||220V / 380V 50Hz / 60Hz|
|Tank Material:||FRP/ Stainless Steel/ Carbon Steel||Control Valve:||Automatic/ Manual|
|Pipe Fitting:||SUS304/ U-PVC||RO Rack Size:||2440*650*1750MM|
|Pre-treatment Tank Size:||Φ600 × 1900MM||Certification:||CE SGS ISO9001|
reverse osmosis water filter system,
domestic water purification system
|1. Product Description|
Reverse osmosis (RO) is a kind of water purification technology that uses a semipermeable membraneunder pressure applied to remove ions, molecules, and larger particles , bactaria and so on from water, and is used in both industrial processes and the production of potable water.
RO reverse osmosis system is the most economical and high efficient purification method.
Water filter reverse osmosis desalting rate ≥99%, desalination rate ≥97%, 99% of organic and bacteria can be removed;
Treated water under good electronic conductivity, one stage ≤10u s/cm, two stage around 2~3u s/cm, EDI≤0.5u s/cm(based on raw water ≤300 u s/cm;
|2. Product Parameter|
|3. Breif Features|
|4. Optional Components|
|A. Regulating wheels||B. PC Touch Screen|
|C. Two-stage RO system||D. PH adjustment|
E. CIP cleaning system
F. Auto or manual control valve
|G. U-PVC or stainless steel pipe||
H. UV sterilizer/Ozone Generator
I. Dosing system(anti-scale)/Water Softener
J. PE or stainless steel raw/pure water tank
|5. Product Processing|
Raw water pump→ Silica sand filter → Activated carbon filter→Water softener → Security filter→ High-pressure pump→ 1st RO system...
1. Raw water pump: provide the pressure to silica sandfilter/active carbon filter
2. Silica Sand filter: get rid of turbidity, suspended matter, organic matter, colloid and so on
3. Activated Carbon filter: Remove the color, free chloride, organic matter, harmful matter and so on
4, Softener: Get rid of calcium and magnesium ions in original / source water, reduce water hardness.
5. Security filter: prevent any deposition of large Particles, most of the bacteria, and viruses into the RO membrane, The accuracy is 5um, for holding back any large particulates such as large iron, dust, suspended matter, impurity.
6. High pressure pump-- Provide the high pressure to RO membrane(at least 2.0 Mpa).
7. RO system-- main part of pure water treatment plant. The desaltation rate upto 99%, it is capable of removing over 99% of ions, bacterias, particles and 98% of organic.
• Drinking water purification
• Effluent and wastewater purification
• Food processing industry
• Car washing
• Fruit syrup production
• Hydrogen production
• Reef aquariums
• Beverage industry
• Brewing industry
• Electronics industries
