Automatic 1000TPD Industrial Water Purification Treatment Plant 50TPH Reverse Osmosis Systems

Basic Information
Place of Origin: Guangzhou, China
Brand Name: Kaiyuan
Certification: ISO9001, CE, SGS
Model Number: KYRO-50TPH
Minimum Order Quantity: >= 1sets
Price: negotiation
Packaging Details: export standard wooden case(plywood), no need to fumigate, suitable for shipping.
Delivery Time: 1-7working days(depand on raw materials stocking)
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: >100sets/month
Detail Information
Product Keywords: 1000TPD Industrial Water Purification Treatment Plant Production Capacity: 500TPH=1000TPD=50000LPH
Electrical Power: 380V 50Hz Tank Material: FRP/ Stainless Steel/ Carbon Steel
Function: Provite Frequency Pressure Application: Building Hotel Restaurant School
Pump: CMP/ Grundfos Control Valve: Automatic/ Manual
High Light:

1000TPD Industrial Water Purification Treatment Plant

,

50TPH Reverse Osmosis Systems

,

50000LPH Water Purification Treatment Plant


Product Description

Automatic 1000TPD industrial water purification treatment plant

50TPH reverse osmosis systems with factory price



Automatic 1000TPD Industrial Water Purification Treatment Plant 50TPH Reverse Osmosis Systems 0

Automatic 1000TPD Industrial Water Purification Treatment Plant 50TPH Reverse Osmosis Systems 1

Automatic 1000TPD Industrial Water Purification Treatment Plant 50TPH Reverse Osmosis Systems 2



Reverse osmosis process uses semi permeable spiral wound membranes to separate and remove dissolved solids,organic, pyrogens, sub micron colloidal matter and bacteria from water. Feed water isdelivered under a pressure of approximately 16 kg/cm2 through reverse osmosis membranes. Waterpermeates the minute pores of the membrane and is delivered as purified water. Impurities in the water are concentrated in the reject stream and flushed to drain. Reverse osmosis is capable of removing 90-99% of total dissolved solids (TDS), 99% of organic, including pyrogens, and 99%bacterials in the feed water.



We provite foreign installation and 24hours online technical support!


Automatic 1000TPD Industrial Water Purification Treatment Plant 50TPH Reverse Osmosis Systems 3



Specification for 50000L/H RO system
Item
Material/Model
Brand
Function
Raw water pump
SS304
CNP/Grundfos
Provide pressure for raw water
Quartz sand filter
FRP
China
Remove large particule
Activated carbon filter
FRP
China
Removesmell,color,bacterial and organic matter



  Water softener

FRP
China
Remove hardness in water
Security filter
SS304 1mircon/5mircon
China
Block impurities greater than 5micron(1micron)
High pressure pump
SS304
CNP/Grundfos
Provide pressure for water into RO membrane
RO membrane
BW30-400IG
DUPONT(DOW)
Remove heavy mental ion,bacterial,virus. Desalination rate is more than 97%
UV Sterilzier
SUS304
USA
Kill 99% bacterial
(For drinking directly)
Ozone Genernator

China
Kill 99%bacterial and keep 2hours.(For making bottled water)



Advantages:

1.Can run and produce water continuously, highly automatic
2.No need chemical to regeneration,easy operation and maintainance
3.RO system uses imported USA DOW membrane
4.Automatic switch on when lack of water,and switch off when no water or full of water
5.RO membrane auto wash and reduce the pollution speed.
6.Low-pressure switch protects high-pressure pump from damage cause by water supply stops.
7.Production water condutivity meter monitors water quality online contionuosly.
8.Input water and dense water pressure meters, monitor the RO differential pressure and remind the time of washing.



Process: raw water+ raw water tank+ raw water pump+Quartz sand filter+ Activated carbon filter+water softener (optional)+ security filter+ high pressure pump+ reverse osmosis system+ pure water tank+ UV sterilizer (ozone generator) + water supply points



Automatic 1000TPD Industrial Water Purification Treatment Plant 50TPH Reverse Osmosis Systems 4

Automatic 1000TPD Industrial Water Purification Treatment Plant 50TPH Reverse Osmosis Systems 5

Automatic 1000TPD Industrial Water Purification Treatment Plant 50TPH Reverse Osmosis Systems 6

Automatic 1000TPD Industrial Water Purification Treatment Plant 50TPH Reverse Osmosis Systems 7


Thank you so much for your value time.Any questions please click "contact now" send us inquiry ! We will reply you within 24 hours. Tel/whatsapp/wechat: +86-13660858152
