Reverse Osmosis Ion Exchange Filtration System 30TPH 250 RO Drinking Water Purifier

Basic Information
Place of Origin: Guangzhou, China
Brand Name: Kaiyuan
Certification: ISO9001, CE, SGS
Model Number: KYRO-30TPH
Minimum Order Quantity: >= 1sets
Price: negotiation
Packaging Details: export standard wooden case(plywood), no need to fumigate, suitable for shipping.
Delivery Time: 20-25working days(depand on raw materials stocking)
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: >100sets/month
Detail Information
RO Membrane: USA DOW Production Capacity: 30TPH
Recovery Rate: 50% - 75% Electrical Power: 380V 50Hz 3Phase Or Others
Membrane Housing: FRP/ Stainless Steel Control Valve: Automatic/ Manual
Function: Purification For Pure Drinking Water Filter Media: Quartz Sand / Activated Carbon
High Light:

ion exchange water purifier

,

ion exchange resin water filter


Product Description

Reverse Osmosis Filter System 30TPH Drinking Water Plant 250 RO Purifiers Treatment


30T/H Water Treatment System Plant



Adopting physical principle, it enables seawater to pass reverse osmosis membrane with a diameter of one ten-thousand of a micron and separates impurities, ion, microbes and colloids from the water so as to meet the water requirements in drinking purpose or for industrial usage, such as cosmetics, pharmacy, electronics and food industries.



Reverse osmosis water purification plants are based on membrane technology that removes approximately 99.5 % salt from the water to make it is suitable for drinking as well as for industrial use.


We treat water from well, river and sea, or as per the customer’s requirement. Compact, skid mounted, factory assembled and tested before delivery assuring the best quality and smooth operation at site. The capacity ranges from 0.25m3/hr to any size you need.



Another, the SWRO desalination system solve the problems of frequent regeneration and cleaning during the use of ion exchanging water purifier.





Feed Temperature 2-40 ℃
Feed water TDS About 35000ppm
Feed pH 3-11
Feed water pressure 0.1-0.3 Mpa
Operation Pressure 4.5-6.0 Mpa
Electric Parameters 380v / 415v / 420v / 480v AC, 50hz / 60hz, 3 phases
Tonnage Electricity Consumption 3.5-7.5 Kw.h / ton
System recovery rate Nearly 40% when operation pressure is near 53 bar.
Design output 1 m3/hr to any size as requested
Produced water quality Portable drinking water



Highlights of RO Desalting plant



1. Continuous water production without the need of regeneration, reducing labor strength.

2. Removing 98% of ions, organic matters and bacteria, with a heat source of more than 98.

3. Online electric conductivity monitoring, ensuring good fresh water quality.

4. PLC microcomputer monitoring, flushing the RO membrane timely.

5. Automatic stop in case of low pressure water shortage and high pressure water sufficiency.



Application Scope

1. Food and beverage industrial water, purified drinking water, beverages, beer,
liquor, health care products such as water purification and preparation of water
2. Integrated circuits, silicon wafers, display tubes and other electronic components of
electronic industrial water rinse water
3. Can be used for filling water bottled water, mineral water and other preparation work
4. Chemical industry, process water / chemical recycled water, chemical products
manufacturing purification and preparation of water



Process: raw water tank + raw water pump + quartz sand filter + activated carbon filter + water softener/chemical dosing system(optional) + security filter + high pressure pump + ro system + pure water tank + UV sterilizer(ozone generator) + precision filter + water supply point



Reverse Osmosis Ion Exchange Filtration System 30TPH 250 RO Drinking Water Purifier 0

Reverse Osmosis Ion Exchange Filtration System 30TPH 250 RO Drinking Water Purifier 1
